Tips to Extend the Life of Your Lithium-Ion Batteries
With the progression of time, lithium-particle batteries keep on losing their life. This corruption is very irritating. In any case, this can be something worth being thankful for according to cell phone producers. All things considered; how might they sell new batteries if the old ones keep on working for quite a long time to come. Be that as it may, you can follow a couple of straightforward tips to expand the life of these units. This can assist you with capitalizing on your telephone battery. Peruse on to discover more.
Top 5 Android Apps for Professional Video Editing
At the University of Michigan, groups of scientists made elite of ideal practices that can assist you with expanding the life of your lithium-particle batteries. We realize that the parts of these battery packs keep on corrupting with the progression of time. These parts incorporate current gatherers, the separator, electrolyte, cathode, and anode.
How to Backup iPhone to Windows PC or Mac
Another investigation found that numerous elements assume their job in the debasement of these battery units. What's more, interestingly, it is conceivable to stay away from these components. How about we look at a portion of those avoidable variables:
How to Clear Cache on iPhone
Most importantly, you might need to shield your battery pack from outrageous temperatures. This is much more significant while the units are being revived. For instance, if your telephone is charging however it has a high temperature, you might need to take it off. Additionally, it's anything but a smart thought to charge your telephone when the temperature is excessively low.
The issue is that outrageous temperatures can quicken the cycle of the debasement of the entirety of the parts of these units. Hence, you might need to revive your batteries when the temperature is in the given reach.
Another significant mix-up to keep away from is to ensure your battery isn't excessively vacant or excessively full. As such, ensure you don't release your battery under 20%. The explanation is that it will put over the top weight on the unit making it debase rapidly.
When your gadget is completely energized, you might need to take it off. In this way, you might not have any desire to leave your telephone charging for the time being. You might need to discover a charging schedule that is advantageous and reasonable for your telephone.
Thirdly, you might not have any desire to quickly charge and release your gadget. Despite the fact that these charges appear to be very helpful, it can cause your battery pack to warm up, which can make it debase. Likewise, you might not have any desire to release your battery rapidly. For instance, you might not have any desire to run eagerly for power application. Accordingly, you might need to utilize a one-ampere moderate charger for your mobile phones. Ultimately, it's anything but a smart thought to store your lithium-particle battery in a soggy climate.
Long story short, you might need to screen the temperature of your gadget and revive and release it at a moderate rate. By following the tips given in this article, you can take advantage of your Lithium-particle batteries.
5 expert suggestions for extending the life of your lithium-ion batteries
Ruggedized design and high energy density for a long lifetime, even in extreme temperatures, are features of industrial grade lithium-ion batteries that power your remote or portable devices. The way the battery is charged, discharged, and the operating temperatures all affect how long it lasts.
In this post, we'll go over how these batteries work and give you our top five ideas for extending the life of your industrial-grade lithium-ion batteries. You'll learn how, just like with your cellphones, computers, or e-bikes, balancing charging speed and rate is critical for industrial applications.
Continue reading...
Top tip 1: Understand the battery language
Lithium-ion batteries have two electrodes, one positive and the other negative. When you charge or drain your battery, electrons travel outside the battery via the electrical current, while ions travel from one electrode to the next. It's as if both electrodes are exchanging ions in and out, as if they're breathing.
Electrons go from the anode to the cathode outside the battery when the battery delivers current. Reverse current allows the battery to recharge by sending electrons back to the anode and allowing lithium ions to re-intercalate in the cathode. This replenishes the capacity of the battery. A cycle is used to describe the entire charging and discharging operation. The number of cycles your battery may go through is determined on the manufacturing process, chemical components, and actual use.
The capacity of a rechargeable battery is measured in Ah. Saft MP 176065 xtd boasts a 5.6 Ah capacity for example, which means that 5.6 A can be delivered in an hour at 25°C, over a cycle.
This capacity is being directly influenced by:
The charging and discharging rate of the battery called the C rate. Charge and discharge currents are typically expressed in fractions or multiples of the C rate: A C charge/discharge means that you will charge or discharge the battery in an hour. A C/2 charge/discharge takes two hours, a 2C charge/discharge takes 30 minutes, etc. Saft’s MP 176065 xtd C rate is 5.6A. A C/2 charging at 2.8A would take approx. 2 hours.
The voltage level that reflects the charge level: in our MP 176065 xtd example above, a 4.2V indicates a full charge, a 2.7V indicates that the battery is completely discharged (cut-off voltage).
The charging, discharging and operating temperature.
Multiple cycles: with time, the battery loses capacity due to the physical and chemical degradation of the electrodes, and the electrolyte.
A good management of the depth of discharge (DoD —the percentage of the capacity which has been removed from the fully charged battery) and of the maximum charging voltage can also enhance the number of cycles that the battery will be able to perform and therefore, its operating life.
This article focuses on the charging best practices but we’ll go through the discharging ones in our next article.
Top tip 2: Respect a CCCV charging process, especially when on floating mode (the charger is your best friend)
Charging a lithium-ion battery is not that simple. The charger you will select has here a key role as the way you will set up parameters impacts your battery lifetime. Don’t just plug it on any power supply nor use a charger designed for another technology (Nickel-Cadmium or Lead), if you don’t want to face safety issues.
Charging properly a lithium-ion battery requires 2 steps: Constant Current (CC) followed by Constant Voltage (CV) charging. A CC charge is first applied to bring the voltage up to the end-of-charge voltage level. You might even decide to reduce the target voltage to preserve the electrode. Once the desired voltage is reached, CV charging begins and the current decreases. When the current is too low, the charge is finished, and the current must be removed.
For instance, to bring your MP 176065 xtd back to its 4.2V end-of-charge voltage, you can apply a 5.6A current. When reaching 4.2V, you maintain this voltage level by slowly decreasing the current to 100 mA or less and then stop it. You may also decide to reach 4.1V only, thus preserving the electrodes’ elasticity and increasing the battery's lifetime.
The capacity of the battery depends directly on the end-of-charge voltage so lowering the voltage will lower the battery capacity. You’ll have to find the right trade-off between the autonomy needed, the minimum voltage at which your device can operate and the longevity of the battery.
Leaving a battery on a permanent charge under a floating current after the CV mode during the charging process is called the floating mode. Solar panel is a typical example of a floating mode application.
Most manufacturers don’t recommend the floating mode as it damages the battery over time. Li-ion chemistry does not need to be maintained thanks to its low self-discharge level. Moreover, if the battery design does not have the right safeguards, maintaining a charge rate into a fully charged cell could lead to overcharged it and an explosion.
Saft’s xtd range is specifically designed to operate in floating mode in safe conditions with a limited aging on a wide temperature range.
Top tip 3: Carefully design your BMS (your other best friend)
Whichever the application, Li-Ion cells must be associated with electronics. This key electronic component is called a Battery Management System (BMS). The mandatory safety features interrupt the discharge/charge to protect the battery against overvoltage or undervoltage. The BMS checks the temperature and disconnects the battery to avoid overheating.
The BMS can also incorporate electronics optimizing a homogeneous charge between each cell in the battery pack (balancing). In a battery associating several cells connected in series, after a while in the field, cells from the pack will age differently. Without this balancing feature in the BMS, the most aged cell of the pack will age faster than the other. As the life duration of the pack is directly related to that most aged cell, a good balancing system will improve the battery's lifespan.
The BMS can be tailored to your use case. Some can display the State of Charge and the State of Health (ex: 85% of State of health means that the battery’s capacity has decreased by 15% since the beginning of its life —an interesting indication as it is understood that a 30% loss of the original capacity means the battery is reaching the end of its chemical life and replacement time is close).
Top tip 4: Lower your charging C rate
At low charging speed (C/2, C/5 or even less), the lithium ions are intercalating themselves smoothly in the graphite sheets, without damaging the electrodes.
When the charge rate increases, this intercalation gets harder and harder. If the rate is too strong, Lithium ions have no time to penetrate the electrode properly and just deposit on its surface, which causes the battery to age prematurely.
Fast charging rates like 4C or 10C are possible, for example for mobile or electric vehicles batteries, but the electrode constructions are different, and the expected lifespan is shorter.
Depending on how much time your application needs to be recharged and your use case, you’ll need to find the right trade-off between the necessary charging time and speed and the aging of the battery. A C/50 charging rate is better for the electrodes but not every application can afford more than 50 hours charging time! A 2C charging time (30m) is possible but will accelerate the aging of the battery.
Therefore, Saft recommends limiting the charge rate of its MP range to C or less.
Top tip 5: Control the charging temperature
Most Li-Ion batteries use graphite type material in one electrode. An elevated charging temperature provokes the exfoliation of the graphite sheets which hastens permanent capacity loss in the battery. This phenomenon can be aggravated when associated to a high charging rate: the charging current increases the temperature and causes an acceleration of the exfoliation phenomenon.
A high voltage level coupled to a high temperature causes the electrochemistry to generate gases inside the cell which accelerates chemistry ageing. Depending on the cell construction, high temperatures can also generate cell swelling. Such a deformation can cause safety hazards when the battery casing or device location have not been designed to support it. Make sure not to exceed the limits set by the battery manufacturer, or —for example— put a cell on full charge for an extended amount of time in an overheated car in the height of summer!
If the battery design does not include the mandatory safeguards to avoid overcharge, over-discharge and over temperature, a cell internal temperature higher than 130°C could lead to a thermal runaway.
Most li-ion batteries can only withstand a maximum temperature of 60°C and are recommended to be charged at a maximum of 45°C under a C/2 charge rate, whereas Saft’s MP range can sustain a C charge rate up to 60°C and even C/5 up to +85°C for the xtd products thanks to its unique design.
Very few batteries can be charged below 0°C. The electrode sheets contract and the electrolyte electronic conductivity gets lower which complicates the intercalation of the ions in the graphite. Lithium deposit can be generated which cause permanent capacity loss. To compensate and allow for the ion to intercalate properly, some manufacturers recommend charging the battery at very slow rate (C/20) when operating below 0°C.
Saft’s MP range can handle charges at very cold temperatures —up to -30°C!— when applying C/8 and even C/5 rates.
Let’s summarize our 5 top tips on how to charge your industrial-grade lithium-ion batteries to optimize their lifespan:
Top tip 1: Understand the battery language. Knowing how a battery works will help you optimize the way you charge and discharge to make the most of your rechargeable battery
Top tip 2: Respect a CCCV charging process, especially when on floating mode (the charger is your best friend): Rechargeable batteries need to follow a specific charging process, usually handled by a carefully selected charger.
Top tip 3: Carefully design your BMS (your other best friend), especially when using multiple cells battery pack.
Top tip 4: Lower your charging C rate: At low charging speed, the ions are intercalating themselves smoothly in the electrode, thus extending the battery’s lifetime.
Top tip 5: Control the charging temperature: Batteries work best when charged at ambient temperature. High or low temperatures lead to premature ageing of the battery.
