The main tools used to repair a mobile phone
Repair and maintenance of mobile phones
Mobile Phone Repair Tools
Tools and equipment for mobile phone repair.
1.Soldering iron: used in welding components
Small such as capacitor, resistor, LED
Duo, transistor, regulator, speaker,
Microphone, display etc. Soldering iron 50
And good enough for most repair jobs
Mobile phones.
2.PCB Holder/PCB Holder (Printed Circuit Board): Bide is used
PCB vinyl to hold the PCB of the mobile phone during welding or repair. It holds a PCB
very strongly and does not allow it to do so and therefore helps in the reform
3.Welding wires:
Used in welding electronic components, integrated circuits or jumpers. The most welding wire is made of tin/.63:37 or 60:40 lead ratio
4.Thinner or PCB cleaner:
Thinner or PCB cleaner is used to clean the mobile phone PCB.
The most common PCB cleaner used in mobile phone repair is IPA or isopropyl alcohol.
It is important to buy only high-quality PCB cleaner because poor quality PCB cleaners can damage the system board.
5.Jumper wire:
This is thin laminated copper wire, or coated used to jump from one point to anotherin mobile phone tracking during repair.
6.Cutter point: it is used for cutting
7.Cutter Blade:
This is used to remove the lamination of the jumper wire. It can also be used for many other purposes.
8.Nose cutting: This is used for cutting.
9.Precision screwdriver:
It is used to unscrew and tighten the screws during the assembly and disassembly of a mobile phone. Precision screwdrivers of T4, T5, T6 and front sizes are good for most mobile repair tasks.
10.Tweezers:
These are required to hold electronic components, integrated circuits, transit wire etc. during welding and de-solding.
1.Brush:
These are used to clean the mobile phone PCB when it is repaired. It is important to purchase only Safe-ESD cleaning brushes.
2.Multimeter:
An electronic measuring device that has the ability to measure voltage, current and resistance. It is used to test and inspect the readings of various parts and components of a mobile phone.
3.Hot air blower:
It is also called the reformulation of the SMD (surface stabilization device) system and the SMD repair system controls the regulation or management of temperature, flow or hot air. Always buy a high-quality Safe-ESD hot air blower.
4.Booster battery: Used to increase mobile phone battery power.
5.Screwdriver kit: It has several screwdriver screwdrivers of different shapes and sizes for disassembling and assembling the mobile phone.
6.Microscope: It is used to see the magnifying display of PCB or electronic components. These are available in different zoom options. Many microscopes can also be connected to a monitor computer.
8.Battery test: This is a device used to test and analyze the status or status of a cell phone battery.
9.Cleaning sponge: This is used to clean the tip of the soldering iron during soldering.
10.Paste paste: Solder paste is a low-melt metal that allows it to be used to join metal workpieces together. It has a lower melting point than metal workpieces.
11.LCD tester: used to check whether the HAT mobile phone LCD screen is defective or not.
